Ceramic Bond Diamond Grinding Tool

2022-03-22

Due to its good chemical stability, small elastic deformation, wide range of hardness tolerance, ceramic bond is widely used in the manufacture of ordinary abrasive tools. However, no matter at home or abroad, there are not many diamond abrasives using ceramic bond (but there are more CBN grinding wheels made of ceramic bond), the main reasons are:

(1) The ceramic bond is brittle and has poor impact resistance and fatigue resistance;

(2) The manufacturing process of the low-temperature sintered ceramic bond suitable for the manufacture of diamond abrasives is much more complex than that of the resin bond;

(3) It is difficult to recover diamond from waste ceramic bond abrasives;

(4) The grinding ability of ceramic-bonded diamond abrasives is between those of resin and metal, so they are replaced by these two kinds of abrasives in many cases.

In recent years, efforts are being made to develop ceramic bond diamond and CBN abrasive tools. Because it can not only be used for grinding superhard materials, but also can process diamond sintered body, natural single crystal, hard ceramics, metals and other materials. When machining these materials, ceramic-bond abrasives outperform resin and metal-bonded abrasives in terms of service life, grinding efficiency, and sharpness.

The manufacturing process of ceramic bond diamond abrasive tools is also composed of raw material preparation, compounding, firing and machining.
